ADAYO lighting DIY high lumen spotlight custom 10W 1000lm CCT3, bezel changeable, screw free design, led down lights manufacturer, [email protected]

DIY high lumen spotlight custom 10W 1000lm B01 led down lights manufacturer

ADAYO lighting DIY high lumen spotlight custom 10W 1000lm CCT3, bezel changeable, water-proof, led down lights manufacture, build in power suply and good quality, [email protected]

Product Specification:
  • Rated Wattage : 10W
  • Luminous : 1000lm
  • Colour Temperature : CCT3
  • Colour Rendering : >80
  • Lifespan : 30000hrs
  • Size:Φ105*59mm, cut Φ85mm :
  • PF : >0.9
  • New ERP. Accept OEM & ODM :
INQUIRY NOW
Pinterest ADAYO light supply recessed downlight custom LED home lighting and commecial lighting OEM linkedin ADAYO lighting OEM indoor light ip65 home light track light and commecial lighting Facebook ADAYO lighting listed company OEM LED ceiling light and ODM  LED spot light  smart wifi lam Twitter ADAYO lighting offer wifi bulb OEM wifi fire rated downlight custom LED downlight and spot l ADAYO wifi bulb | smart wifi led bulb | wifi led light bulbs
Product Details
Documents download



Over view:

ADAYO lighting diy high lumen spotlight custom 10W 1000lm B01, led down lights manufacturer delivery fast and good quality;

We are diy ceiling light custom, led down lights manufacturer, this diy ceiling lights with triac dimming 220-240v~50/60Hz, PF>0.9, RA>80, with new ERP standar;

This diy high lumen spotlight custom also with simple design, comfortable light feeling and easy installation. There are four colors of the bezels choosing, brushed nickel, chrome, silver, black. Most of customer like brushed nickel color bezels for change;

It can be installed directly into the insulation, waterproof IP65 canbe used in wet application.











Features:

ADAYO lighting diy high lumen spotlight custom 10W 1000lm B01, led down lights manufacturer features as below:

1. With aluminum heat sink, keep life span 30000hours;

2. Four colors of bezels optinoal: brushed nickel, chrome, silver, black;

3. Size:105x59mm, cut85mm;

4. Clear light beam angle 100° with no dark spots and has gentle fade to edges for uniform lighting design;

5. Quality SMD 2835, single color or CCT3 optional;

6. Simple design, comfortable light feeling and easy installation.



ADAYODIYhighlumenspotlightcustom



Product detail:

ADAYO lighting diy high lumen spotlight custom 10W 1000lm B01, led down lights manufacturer for UK market with CE and BS476-21/22, with diffirent color bezels choosing detail as below:

1. Driver: Built-in power supply

                Input:220-240v~50/60Hz  Max.0.07A

               Output: 52V±10% 165mA (CC), PF: >0.9, Prated: 10W;

2. Body: Iron and die-cast aluminum heat sink, good heat dissipation, life span 30000Hrs, warranty 3 years, can be installed directly in to the insulation;

3. Light source: SMD2835, single color or CCT3 optional;

4. Water proof IP65 from front, you can use it into wet application;

5. Bezel: Four colors of bezels optinoal: brushed nickel, chrome, silver, black.

 ADAYODIYhighlumenspotlightcustom



Specification:

ADAYO lighting diy high lumen spotlight custom 10W 1000lm B01, led down lights manufacturer for UK market with CE and BS476-21/22, CCT3, beam angle 100°, with diffirent colors, specification as below:

DIY high lumen spotlight custom specification



Item Name:   SL001-B01 Input Voltage(V):                220-240v ~50/60Hz Max.0.07A
Watt (W): 10 Lumen(lm): 1000
Lamp Body Materia:           Aluminum+PC CRI (Ra>): >80
Certification: CE, Rohs, BS476-21/22              IP Rating:    IP65
Life span: 30000Hrs Beam angle: 100°
Warranty: 3Years CCT: Single color or CCT3 optional
Installation: Recessed  spotlight Bezel: Brushed nickel, Chrome, Silver, Black
Driver: pf>0.9 Light source:  SMD2835



ADAYODIYhighlumenspotlightcustom



Application:

ADAYO lighting diy high lumen spotlight custom 10W 1000lm B01, led down lights manufacturer, beam angle 100°, with diffirent colors bezels choosing application as below:

This diy ceiling light custom save more than 90% of power consumption without losing any brightness.

LED becomes the most popular light source all over the world. This ceiling light made of high quality metal materials, safe and long lifespan.

Perfect for living room, hall, office, store, supermarket, hotel residence, restaurant, hotel, hall, show room, shop window, assembly room, factory, etc.



ADAYODIYhighlumenspotlightcustom



Brief introduction of ADAYO Lighting:

ADAYO lighting diy ceiling light custom, dimmable led spotlights wholesale since 1993, listed in 2017, the main modes of cooperation are OEM, ODM and SKD. Industrial park area: 560000sqm.

There are three main business line of ADAYO lighting: LED lighting, LED package and LED big power supply;

With R&D laboratory covered 1200m² with international standard;

R&D team more than 60 people, one third of them with more than 20 years of experience in the lighting industry;

Work Shop 5000 SQM  with more than 300 works and 50 production lines;
