Tensile test is one of the tests in the safety test, this tester is designed to test whether the power cord clamping device is firm. The force generated by the torque motor is used to perform a tension test on the power cord of the sample under test. In the production of LED flush mount lighting and spotlights, tensile testing is an essential safety test for verification, material or supplier changes and design changes.
The specific steps of ADAYO lighting, flush mount lighting manufacturer and kitchen ceiling spotlights custom, LED flush mount lighting material tension test are as follows:
1. Select the corresponding weights according to the sample wire being tested in accordance with the following table.
Rally specifications:
|
Sample weight(kg)
|
Pull(N)
|
Torque(N.M)
|
Choose weights(N)
|
|
≤1
|
30
|
0.1
|
10
|
|
4＞x＞1
|
60
|
0.25
|
25
|
|
＞4
|
100
|
0.35
|
30
|
2. a. Screw the conductor introduced into the terminal and inside the terminal screw (if any) tightly enough to prevent the conductor from easily changing its position.
b. Use the flexible wire fixing frame in the conventional way, first have vernier calipers to measure the diameter of the flexible wire fixing frame screws, and then tighten the clamping screws with a hand batch according to the specified 2/3 torque.
3. Make a mark on the wire about 20mm from the flexible wire fixing frame, and then fix the sample to be tested on the test equipment.
4. Turn on the power of the equipment to set the number of tension (25 times) and torque time (60s).
5. Place the selected weight on the hook on the left side of the device.
6. Press the "Start" button on the operation panel to conduct the tension test. After the test is completed, remove the test sample and make a mark on the wire about 20mm away from the flexible wire fixing frame before loosening the fixing frame screw.
7. Test completed, using vernier calipers to measure the distance shifted by the first and twenty-fifth pull.
During the tension test, after the test sample is fixed, it should be marked at 20mm from the flexible wire fixing frame before and after the test in order to measure the sample shift distance before and after. In the application of pressure can not pull hard, each time 1s and in the torque test, nylon rope need to be around the outer surface of the sleeve three times.
ADAYO lighting as a flush mount lighting manufacturer conducts tests in strict accordance with GB7000.1 and IEC 60598. There should be no visible movement of the conductor inside the terminal during and after the test, and the cable and flexible wire should not be damaged. If it is presumed that the terminal plays a part of the role of the flexible wire holder (for example, the wire between the flexible wire holder and the terminal is stretched), to confirm that the role of the flexible wire holder is independent of the electrical connection, the connection between the conductor and the terminal should be loosened and re-tested. And in the first and twenty-fifth tensile period, the mark for a should not exceed 2mm, for the test passed.
As a flush mount lighting manufacturer and kitchen ceiling spotlights custom, ADAYO lighting is committed to becoming the customer's R&D department and manufacturing department, providing customers with high-quality products and services, and creating value for customers. Both the raw materials for the lamps and the whole flush mount lighting need to pass many tests. Save costs while ensuring high quality, and achieve mutual benefit and win-win results.
